PDC 2 — Double Station Polishing Machine with Dust Collector

Quiet two-stage air purifier capturing respirable dust from laser operations. Features: • Can be used in laser machines for dust collection • Captures airborne dust that is respirable & dangerous to the operator • Reduces airborne particles • Creates a healthier working environment • Designed to capture dust produced in the jewellery industry • Very quiet (65db), easy to install on castor wheels • Plugs into any 220 Volt supply • Two-stage filtration Specifications: • Dimensions: 14" x 14" x 33" (L x B x H) — size can vary, please confirm • 220 Volts • Sound level: 50db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Air purifier for laser machines with optical auto-sync and three-stage filtration. Features: • Can be used in laser machines for better dust collection • Reduces airborne particles • Designed to trap & recover precious dust during laser operations • Auto detect and sync with laser or other machines by optical sensor • On/off operation prolongs motor & filter life and saves power • Three-stage filtration • HEPA filter option available • Sensor option available to save electric current Specifications: • Dimensions: 15" x 12" x 24" (L x B x H) • Weight: 22 kgs (approx.) • Power: 220V, 60Hz, 1000 watts • Sound level: 60db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Compact all-in-one repair table for jewellery showrooms & factories: filing, polishing, steaming and ultrasonic cleaning. Features: • Highly useful facility for jewellery showrooms & factories • Bench polishing motor • Exclusive wooden laminated top • Pocket cloth filter, 5 to 7 micron • Common dust collector for filing & polishing • Aerodynamically designed hood • LED light with toggle switch on hood • Tube light with flexible arm for the filing table • Foot shaker lever for dusting the dust in tray • In-built silencer for noise reduction • Steamer & ultrasonic machine provided • Provision for micro motor and hand pieces • Gold melter machine can also be provided Specifications: • Dimensions: 63" x 24" x 48" (L x B x H) • Suction motor: ¾ hp, 220V — starting 1.7A, running 1.1A • Bench polisher: ¾ hp, 220V — starting 2A, running 1.5A • CFM: 250 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

High-capacity dust collector serving six to eight polishing stations. Features: • Strong suction motor • Pocket cloth filter of 5 to 7 micron • Motorised vibrator for dusting the dust in tray • Inbuilt silencer for noise reduction • Lockable tray for dust • DOL starter for motor • Six to eight stations can be catered • 8" dia suction Specifications: • Dimensions: 3' x 3' x 6½' (L x B x H) • Suction motor: 5 hp, 440V — starting 5A, running 4.6A • Vibrator motor: ¼ hp, 440V — starting 1A, running 0.6A • CFM: 250 per station • Sound level: 75db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Standalone electro-polishing machine that polishes up to 250g of gold jewellery in one go with >99% gold recovery. Features: • Standalone machine with 10 litres capacity • Up to 250 grams of gold jewellery can be polished at one go • Polishing liquid suitable for 8KT to 22KT yellow, white and pink gold • Process time: 15 to 45 minutes • Extremely good surface finish on inside and outside • Substantial saving on filing & polishing process & gross loss % • More than 99% recovery of gold from waste solution • Solutions used are non-hazardous, environmentally safe & user friendly • Two inbuilt containers for rinsing the jewellery, saving precious metal & liquid • Used solution drains to the tank below via a drain valve to avoid spillage • Smaller machines available for 250 gram process Specifications: • Dimensions: 37" x 31" x 47" (L x B x H) • Power supply: 230 Volts, 50 Hz • Weight (empty): 30 kgs (approx.) • Glass media: 0.5 to 0.8 mm • Rectifier: 12 Volts, 25 amps Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Economical filing table with dust collector. Features: • Filing MS table • Fixed drawer & to-and-fro movement of the table top • Drawers provided • Very good suction • Cloth & paper filter for better collection • Air flow from above for pushing the dust toward the suction • Openable MS hood Specifications: • Dimensions: 26" x 29" x 50" (L x B x H) • Motor: ¾ hp, 3 phase • Filters: cloth & paper, approx. 5 micron • CFM: 250 • Sound level: 60db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Hand wash station with SS basin, swiveling taps and cartridge filtration with water recycling. Features: • PP body with SS wash basin & swiveling tap • PP settling tank with pump & cartridge filter • Level switch for auto operation • Two cartridge filters of 5 to 10 micron • Machines available in desired sizes as per your specification • Machine is on wheels for easy mobility Specifications: • Dimensions: 3' x 20" x 3' (L x B x H) approx. • Input: 220V AC / 50Hz • Pump motor: 0.5 HP Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Three-tap hand wash station with a choice of dish-cartridge filtration plant or jumbo filter for fine dust recovery. Features: • PP settling tank with SS wash basin (3 taps) • PP tank size 48" x 20" x 36", PP 8mm thick • SS wash basin 48" x 20" x 8" x 10", SS 304/18g • PP partition 3 nos, 4 compartments, SS net 3 nos • MS angle frame with wheels • Option 1 — Dish cartridge filtration plant (14" dia) with PP frame: jumbo cartridge 2" dia x 20" long x 6, controller with magnetic float sensor & wiring, 1 hp pump, CPVC plumbing, 220V AC 1 phase • Option 2 — Jumbo filter 4" dia x 20" long x 6 (5/10 micron): controller with magnetic float sensor & wiring, 1 hp pump, CPVC plumbing, MS angle frame, 220V AC 1 phase Specifications: • PP tank: 48" x 20" x 36" (8mm thick) • SS wash basin: 48" x 20" x 8" x 10" (SS 304/18g) • Pump: 1 HP • Power: 220V AC, 1 phase Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Extremely space-efficient miniature polishing dust collector with built-in motor. Features: • Extremely space efficient • Filtration traps fine particles down to 10 microns • Heavy steel body • Suction unit with built-in polishing motor • Very silent machine • Inbuilt LED light • Rotary switch for operation • Maximum wheel size 4 inches diameter • Acrylic hood fitted to cover the machine from the front Specifications: • Dimensions: 22" x 12" x 18" (L x B x H) • 2800 RPM, 220 Volts • CFM: 200 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Single-station bench polishing machine with built-in dust collector. Features: • Strong suction motor • Bench polishing motor • On/Off switch • Exclusive wooden laminated top with drawer & lock • Pocket cloth filter of 5 to 7 micron • Aerodynamically designed MS hood, tapered for greater suction • LED light with toggle switch on the hood • Foot shaker lever for dusting the dust in tray • Inbuilt silencer for noise reduction • Locking facility • Single bag filter also available in the same machine Specifications: • Dimensions: 28" x 25" x 48" (L x B x H) • Suction motor: ¾ hp, 440V — starting 1.7A, running 1.1A • Bench polisher: ¾ hp, 440V — starting 2A, running 1.5A • Also available in single phase 220V • CFM: 250 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Double-station bench polishing machine with single removable filter bag and cartridge secondary filter. Features: • Strong suction motor • Two bench polisher motors • Exclusive wooden formica top with two drawers • Single filter bag easily removable; cheap disposable primary filter with cartridge filter for secondary collection • Aerodynamically designed MS hood for greater suction, big hood size • More filter capacity • LED light with toggle switch on the hoods • This machine is without foot shaker • Inbuilt silencer for noise reduction • Locking facility Specifications: • Dimensions: 51" x 28" x 48" (L x B x H) • Suction motor: 1½ hp, 440V — starting 2A, running 1.5A • Bench polisher: ¾ hp, 440V — starting 2A, running 1.5A • Also available in single phase 220V • CFM: 200 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

• Filing and setting table with built-in dust collection • Recovers precious metal dust generated during filing and setting work • For jewellery manufacturing workshops

Split lap machine with dust collection and 30° angled hood for visibility. Features: • Strong suction motor • Split lap motor • Exclusive wooden laminated top with drawer • Pocket cloth filter of 5 to 10 micron • 30 degree angle for maximum visibility • Foot shaker lever for dusting the dust in tray • Inbuilt silencer for noise reduction • Locking facility • Extra suction chamber on the bottom of the hood for better collection • LED light provided • Closed hood model also available • Single pocket filter option available Specifications: • Dimensions: 27" x 23" x 47" (L x B x H) • Suction motor: ¾ hp, 440V — starting 1.7A, running 1.1A • Split lap motor: ¾ hp, 440V — starting 2A, running 1.5A • Also available in single phase 220V • CFM: 250 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Compact wet & dry vacuum cleaner for tight spaces. Features: • Can be used for dry & wet application • One strong suction 0.5 hp motor, 220V • Easily movable on castor assembly • 10 micron filters • Light in weight, about 9 kgs • Suitable for places where bigger vacuum machines cannot reach • Dust collection in the SS tank • All fittings provided with the machine Specifications: • Dimensions: 13" x 13" x 30" (L x B x H) • ½ hp carbon motor, 1000 watts • Capacity: 30 litres Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Magnetic polisher for surface finishing of intricate areas using magnet-driven SS pins. Features: • Magnetic polisher for surface finishing • Powder-coated MS body • One-piece PP container • Polishes surfaces even where hands and tools cannot reach • SS pins spun around by powerful magnets • Auto reverse & forward with inbuilt timer • Pins & liquid can be provided with the machine for better results Specifications: • Dimensions: 15" x 15" x 22" (L x B x H) • Power: 1 hp, single phase • Container size: 10" dia x 7" H • Weight: about 50 kgs • Variable speed option available Manufactured by Professional Engineering Works (ISO 9001, CE marked).

Micro setting table with solid-surface top, microscope vice and two-stage dust collector. Features: • Micro setting table with solid-surface (Korean) top • SS tray at the centre of the table for vice placement & better dust collection • Suction on the collar of the SS tray on three sides • Double SS tray for safety of the stone (trapped in the tray) • Microscope vice & LED light provided • Two-stage filtration dust collector, very silent at 68db • Good leg room for the operator • 2" dia PVC flexible pipe to the dust collector for collection from the SS tray Specifications: • Square dust collector (single suction): 22" x 14" x 18" (L x B x H) • Table: 30" x 23" x 43" (L x B x H) • Suction motor: ¾ hp, 440V — starting 1.7A, running 1.1A • CFM: 250 • Sound level: 68db (approx.) Manufactured by Professional Engineering Works (ISO 9001, CE marked).
